Product Description
● Qauv TSIS MUAJ: EC65(x)
● Txuj: IEC60947-5-1, IEC60947-4-1
● Rated tam sim no: 65A
● Rated ua hauj lwm voltage: 220V ~ 690V
● Rated rwb thaiv tsev voltage: 690V
● Tus naj npawb ntawm tus ncej: 3P
● Tus pab tiv tauj: 1NO+1NC
● Kev siv qeb: AC3, AC4
● Txoj kev txhim kho: DIN-rail lossis ntsia hlau ntsia
Taw qhia
Lub EC65(x) magnetic contactor yog cov khoom siv hluav taws xob hauv lub xeev tsim los muab kev tswj xyuas meej thiab kev hloov pauv ntawm cov khoom siv hluav taws xob hnyav hauv kev lag luam thiab kev lag luam. Nrog nws cov thev naus laus zis siab heev thiab cov yam ntxwv tshwj xeeb, nws muaj kev txhim kho tseem ceeb tshaj li cov neeg siv khoom ib txwm muaj.
Featuring lub compact thiab robust tsim, EC65 (x) magnetic contactor suav nrog ib co coil, hu, actuator, thiab auxiliary contacts, kom ntseeg tau tias kev ua tau zoo hauv kev xav tau ib puag ncig. Nws txhim kho kev tsim kho thiab cov khoom siv ua kom muaj zog ntxiv thiab kev cia siab rau lub sijhawm ntev.
Lub EC65(x) magnetic contactor muaj qhov zoo tshaj plaws piv rau nws cov thawj, LC1D65 AC Contactor. Thaum lub zog tswj tau siv, lub kauj nyob rau hauv EC65 (x) energizes, tsim ib tug haib magnetic teb uas zoo ua hauj lwm tus actuator. Qhov no ua rau muaj kev hloov pauv sai thiab meej ntawm cov neeg sib cuag, ua kom muaj kev sib txuas ntawm cov hluav taws xob circuits.
Nrog nws ntau yam thiab yoog raws, EC65(x) magnetic contactor pom kev siv dav hauv ntau daim ntawv thov, suav nrog kev tswj lub cev muaj zog, teeb pom kev zoo, cov khoom cua sov, thiab lwm yam khoom siv hluav taws xob hnyav. Nws yog muaj nyob rau hauv ntau qhov ntau thiab tsawg thiab configurations, tso cai rau compatibility nrog txawv voltage thiab tam sim no yuav tsum tau.
Txhawm rau ua kom pom kev ua tau zoo thiab kev nyab xeeb, EC65(x) magnetic contactor tuaj yeem ua ke nrog kev tswj xyuas ntxiv xws li thermal overload relays lossis lub cev muaj zog pib. Qhov kev sib xyaw ua ke no muab kev tiv thaiv zoo thiab txhim kho tag nrho cov kev ua haujlwm ntawm cov tshuab hluav taws xob.
Ua raws li cov qauv kev lag luam xws li IEC60947-5-1 thiab IEC60947-4-1, EC65(x) magnetic contactor lav kev lag luam txhim khu kev qha thiab ua raws li cov cai tswj kev nyab xeeb.
Hauv cov ntsiab lus, EC65(x) magnetic contactor hloov LC1D65 AC Contactor thiab sawv cev rau kev nce qib tseem ceeb hauv kev tswj hluav taws xob. Nws cov yam ntxwv siab heev, durability, thiab compatibility nrog ntau yam kev siv ua rau nws yog ib qho kev xaiv zoo tshaj plaws rau kev tswj cov hluav taws xob hnyav hauv kev lag luam thiab kev lag luam. Los ntawm kev muab cov kev ua tau zoo, kev ntseeg siab, thiab ua raws li cov qauv kev nyab xeeb, EC65(x) magnetic contactor teeb tsa tus qauv tshiab hauv kev hloov hluav taws xob thiab tswj.
Feature
● Nyiaj-phooj ywg Magnetic AC Contactor muab kev ua haujlwm zoo.
● Kev nthuav dav ntawm cov txheej txheem pabcuam kev sib cuag kom tau raws li ntau yam kev thov.
● Tsim los tswj cov kev hloov pauv loj dua, ua kom cov khoom siv ruaj khov ua haujlwm.
● Exceptional adaptability rau ib puag ncig tej yam kev mob, guaranteeing txhim khu kev qha kev ua tau zoo txawm nyob rau hauv nyuaj tej chaw.
Technical Data
|
Qauv |
EC65 (x) |
||
|
Ncej |
3P |
||
|
Rated rwb thaiv tsev voltage (Ui) |
V |
690 |
|
|
Rated ua haujlwm voltage (Ue) |
V |
380/400, 660/690 |
|
|
Rated thermal tam sim no (Ith), AC -1 |
80 |
||
|
Rated ua haujlwm tam sim no (Ie) |
AC -3, 380/400V |
A |
65 |
|
AC -3, 660/690V |
42 |
||
|
AC -4, 380/400V |
28 |
||
|
AC -4, 660/690V |
14 |
||
|
Rated ua haujlwm fais fab (Pe) |
AC -3, 380/400V |
kW |
30 |
|
AC -3, 660/690V |
37 |
||
|
AC -4, 380/400V |
15 |
||
|
AC -4, 660/690V |
11 |
||
|
Neeg kho tshuab lub neej |
×104 sij hawm |
900 |
|
|
Hluav taws xob lub neej |
AC -3 |
90 |
|
|
AC -4 |
17 |
||
|
Ntau zaus ntawm kev ua haujlwm |
AC -3 |
Sijhawm/teev |
600 |
|
AC -4 |
300 |
||
Coil yam ntxwv
|
Qauv |
EC65 (x) |
||
|
Rated tswj voltage (Us) |
50Hz, 50/60Hz |
V |
24, 36, 48, 110, 127, 220/230, 240, 380/400, 415, 440 |
|
Kev ua haujlwm ntau |
Kev ua haujlwm voltage |
V |
(85% ~ 110%) Peb |
|
Tshem tawm voltage |
(20% ~ 75%) Peb |
||
|
Coil zog |
Nyob rau hauv maj |
VA |
200 |
|
Muab kaw |
15-20 |
||
|
Hwj chim |
W |
6-10 |
|
Sib cuag
|
Auxiliary contacts specification |
A |
11 |
|
|
Rated thermal tam sim no (Ith) |
A |
10 |
|
|
Rated ua haujlwm voltage (Ue) |
AC |
V |
380 |
|
DC |
220 |
||
|
Rated tswj muaj peev xwm |
AC -15 |
VA |
360 |
|
DC -13 |
W |
33 |
|
