Product Description
● Qauv TSIS MUAJ: WGS SF6 LBS
● Rated Tam sim no: 630A
● Ua Haujlwm Voltage: 12kV, 24kV, 36kV
● Muaj peev xwm tawg
● Compact loj thiab lub teeb yuag
● Txuj: IEC60256-1, 1997, IEC60420
Taw qhia
WGS-12/24/36kV SF6 LBS yog ib qho hluav taws xob hluav taws xob sab hauv tsev uas tsim los rau cov khoom siv hluav taws xob thiab cov khoom siv hluav taws xob. Nws siv SF6 roj ua ib qho arc-extinguishing thiab rwb thaiv tsev nruab nrab. Nrog nws txoj kev hloov pauv, hloov-tawm, thiab lub peev xwm hauv av, nws muaj txiaj ntsig zoo tiv thaiv thiab tswj cov khoom siv hluav taws xob.
WGS -12/24/36kV SF6 LBS yog tshwj xeeb tshaj yog haum rau lub nplhaib net txee, cable ceg txee, thiab tis switching substations. Tsis tas li ntawd, WGS-12/24/36kV-D SF6 LBS variant ua ke nrog SF6 LBS nrog lub fuse rau kev tiv thaiv ntxiv. Ob qho qauv ua raws li cov qauv tsim los ntawm IEC{10}} (1997) thiab IEC60420. Cov kev txhim khu kev qha thiab ntau yam SF6 LBS pab txhawb kev ua haujlwm zoo ntawm cov tshuab hluav taws xob, ua kom muaj kev nyab xeeb thiab tswj tau hauv ntau daim ntawv thov.
Cov txiaj ntsig
● Lub peev xwm tawg tau siab: SF6 LBS tuaj yeem cuam tshuam cov kab hluav taws xob hauv qab kev thauj khoom thiab luv-circuit. Nws lub peev xwm tawg tau ntau tshaj li ntawm cov tsoos load break keyboards, tso cai rau nws los tswj cov dej ntws ntau dua thiab cov khoom thauj.
● Cov khoom siv hluav taws xob siab thiab kev ruaj ntseg: SF6 LBS siv cov pa roj SF6 siab ua qhov nruab nrab arc-quenching, muab hluav taws xob zoo heev thiab kev ruaj ntseg. Kev ua haujlwm siab rwb thaiv tsev thiab lub peev xwm arc-quenching ntawm SF6 roj pab kom lub load tawg hloov mus ua haujlwm ruaj khov nyob rau hauv high voltage thiab loj tam sim no.
● Kev ntseeg siab: SF6 LBS muaj kev txhim khu kev qha thiab kev ua haujlwm zoo hauv ntau yam ib puag ncig. Nws tsis tshua muaj kev cuam tshuam los ntawm cov av noo, muaj kuab paug, thiab lwm yam sab nraud, ua rau nws tsim nyog rau kev ua haujlwm ntev hauv kev ua haujlwm hnyav.
● Compact me me thiab lub teeb yuag: Piv rau cov tsoos huab cua load break keyboards, SF6 LBS muaj ib tug me me hneev taw thiab sib dua. Qhov no ua rau nws yooj yim dua rau kev teeb tsa thiab xaim hauv daim ntawv thov kev lag luam, tshwj xeeb tshaj yog nyob rau hauv qhov chaw tsawg.
● Lub neej ntev: Vim yog kev siv cov khoom zoo thiab cov qauv tsim, SF6 LBS muaj lub neej ua haujlwm ntev dua. Nws cov rwb thaiv tsev kev ua tau zoo thiab arc-quenching muaj peev xwm nyob ruaj khov siv mus ntev, txo qhov kev xav tau ntawm kev saib xyuas thiab hloov.
Technical Data
|
Yam khoom |
Chav tsev |
Kev ntsuas |
||
|
Rated voltage |
KV |
12 |
24 |
36 |
|
Rated zaus |
Hz |
50 / 60 tzs |
||
|
Rated tam sim no |
A |
630 |
||
|
Rated load breaking tam sim no |
A |
630 |
||
|
Rated cable them tam sim no |
A |
10 |
||
|
Rated luv Circuit Court ua tam sim no |
KA |
50 |
||
|
Peak tiv taus tam sim no |
KA |
50 |
||
|
Rated luv Circuit Court tiv taus tam sim no |
KA |
25 |
||
|
Rated luv luv Circuit Court ntev |
S |
1 |
||
|
Fais fab zaus withstand voltage, theem rau theem / theem |
KV |
28 |
50 |
70 |
|
Fais fab zaus tiv taus voltage, cuam tshuam qhov sib txawv (tus nqi zoo) |
KV |
32 |
60 |
82 |
|
Lightning impulse withstand voltage, theem rau theem / theem rau hauv av |
KV |
75 |
125 |
170 |
|
Lightning impulse withstand voltage, cuam tshuam qhov sib txawv |
KV |
85 |
145 |
195 |
|
Neeg kho tshuab lub neej |
Sijhawm |
Ntau dua lossis sib npaug li 5000 |
Ntau dua lossis sib npaug li 2000 |
|
|
Kev tiv thaiv qib |
IP3X |
|||
